PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-5
FREQUENCY
The Frequency parameter must be set in accordance with the required satellite
transponder frequency. The frequency can be acquired from the satellite
transponder information.
In this example, the valid frequency range is between 0.95 and 2.15GHz.
Frequency
1.068000 [GHz]
<0.950000 - 2.150000>
The valid frequency range varies according to the selected band.
Table 4-1: Band Frequency Range
BAND MINIMUM FREQUENCY MAXIMUM FREQUENCY
Ku-Band
10.700000GHz 12.750000GHz
C-Band
3.200000GHz 4.200000GHz
L-Band
0.950000GHz 2.150000GHz
SYMBOL RATE
The Symbol Rate parameter must be set according to the satellite transponder
symbol rate. The Symbol Rate value can be acquired from the satellite
transponder information or can be calculated, with the bit rate information.
Symbol Rate
29.818000 [Mbaud]
<01.000000 - 45.000000>
Available values range from 01.000000 to 45.000000 Mbaud.
NOTE
It is important to input the accurate Symbol Rate down to the sixth digit after
the decimal point.
