PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-13
Table 4-2 lists the different bands, and their respective frequency ranges.
Table 4-2: Band Frequency Designations
BAND FREQUENCY
L-Band
0.950000-2.150000GHz
C-Band
3.200000-4.200000GHz
Ku-Band
10.700000-12.750000GHz
SYMBOL RATE
The Symbol Rate menu is used for adjusting the receiver’s symbol rate to the
symbol rate of the received signal.
Symbol Rate
27.000000 [Mbaud]
<00.016000 – 45.000000>
Available values range from 00.016000 to 45.000000 Mbaud
NOTE
The symbol rate must be set to match the exact symbol rate value used by the
satellite transponder.
MODULATION
The Modulation menu allows setting the PVR 6000 receiver to the relevant
modulation method.
Modulation
1{ DVBS-QPSK
2{ DSNG-8PSK
3{ DSNG-16QAM
4 DVBS2-N-QPSK
