User Manual
Operation and Management
Page 4-14 (Rev. 4.1/ SW v1.60/ December 2006)
5{ DVBS2-N- 8PSK
6{ DVBS2-N-16APSK
7{ DVBS2-S-QPSK
8{ DVBS2-S-8PSK
9{ DVBS2-S-16APSK
Available modulation options are:
• DVBS-QPSK
• DSNG-8PSK
• DSNG-16QAM
• DVBS2-N-QPSK
• DVBS2-N-8PSK
• DVBS2-N-16APSK
• DVBS2-S-QPSK
• DVBS2-S-8PSK
• DVBS2-S-16APSK
ROLL- OFF
The Roll off menu is used for setting the receiver’s roll-off factor value
according to the roll-off factor of the transmitted signal.
The Roll-off factor is the factor that is used for the base-band shaping of the
transmitted signal. Set the Roll-Off factor in accordance with the transmitted
Roll-Off factor.
Roll-off
1 35%
2{ 25%
3{ 20%
Available options for the Roll-off factor are:
• 35%
• 25%
• 20%
PILOTS
In order to expedite carrier recovery, the standard allows two operating modes for
each modulation type: Pilot-less (i.e. no Pilot symbols are inserted) and Piloted,
where Pilot symbols are inserted to aid carrier synchronization. The Pilots menu
enables to choose between the two operating modss.
