PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-15
Pilots
1 OFF
2{ ON
The available options are:
• OFF – selects Pilot-less mode
• ON - selects Piloted mode
NOTE
The PLSCODE informs the receiver regarding the pilot configuration, which
resides in the PLHEADER. Usually, only a few modes, such as 8PSK rate 2/3,
16APSK rate 2/3 and 3/4, and 32APSK rate 3/4, need pilot assistance for carrier
recovery.
FEC RATE
The FEC Rate menu enables to set the Forward Error Correction rate according
to the FEC rate of the transmitted signal.
FEC Rate
01 1/4
02{ 1/3
03{ 2/5
04{ 1/2
05{ 3/5
06{ 2/3
07{ 3/4
08{ 4/5
09{ 5/6
10{ 7/8
11{ 8/9
12{ 9/10
