PVR 6000 Series
Professional Integrated Receiver Decoders
Page 4-27
• FEC – this parameter allows the user to enable FEC for
the ATM receiver.
MODE
The Mode parameter allows the user to set the operational mode of the ATM
receiver. The following is the front panel Mode screen:
Mode
1 { E3
2  DS3
2 { STM-1 MULTI MODE
4 { STM-1 SINGLE MODE
5 { OC-3 MULTI MODE
6  OC-3 SINGLE MODE
VPI ADDRESS
The VPI Address parameter allows the user to set the path address for the ATM
receiver. The following is the front panel VPI Address screen:
VPI Address
01[Hex]
<00-FF>
The available values range from 00 to FF.
VCI ADDRESS
The VCI Address parameter allows the user to set the channel address for the
ATM receiver. The following is the front panel VCI Address screen:
VPI Address
0020[Hex]
<0000-FFFF>
The available values range from 00 to FF.
FEC
The FEC parameter allows the user to enable or disable FEC for the ATM
receiver. The following is the front panel FEC screen:
