User Manual
Operation and Management
Page 4-28 (Rev. 4.1/ SW v1.60/ December 2006)
VPI Address
1 Enable
2 { Disable
4.2.2.5. IP Receiver Configuration Menu
This section details the front panel menus that enable configuring the IP receiver
in a PVR 6000 IP front end device.
The following is the IP Receiver Configuration menu as it is displayed on the
PVR 6000 front panel screen:
Receiver 1-2-1
1 MPEGoIP Input 1
2 MPEGoIP Input 2
3 General
The available options are:
• MPEGoIP Input 1 - allows the user to configure the MPEGoIP receiver
connected to the rear panel MPEGoIP IN 1 interface
• MPEGoIP Input 2- allows the user to configure the MPEGoIP receiver
connected to the rear panel MPEGoIP IN 2 interface
• General - allows the user to configure parameters such as redundancy, De-
jittering delay, and FEC.
MPEGOIP INPUT 1
The MPEGo-IP Input 1 sub-menu allows the user to configure the MPEGoIP
receiver connected to the rear panel MPEGoIP interface.
NOTE
MPEGoIP Input 2 menu is identical to the MPEGoIP Input 1 menu
MPEGoIP Input 1 1-2-1-1
1 Physical Link
2 Logical Source
3 FEC
To Next Page
