Introduction
22 I3031-14.0 HBM: public Quantum
X
by VDE, and stand for maximum safety when working
with dangerous voltages.
S MX403B voltage module
The module has 4 inputs with lab connectors for
voltage measurement (1000 V CAT II, 600 V CAT III).
The module and entire production have been certified
by VDE, and stand for maximum safety when working
with dangerous voltages.
Notice
When using the modules MX403B or MX809B, please
refer to the separate operating manual, document num
ber A3757.
S CX22B or CX22B-W (WLAN) Data recorder
The module is used for local recording of measure
ment data.
S CX27B EtherCAT®/Ethernet gateway
The module is used to connect QuantumX modules to
the EtherCAT® fieldbus or the Ethernet.
S MX878B Analog output module
The module has 8 scalable voltage outputs ("10 V)
that can be assigned with a system signal or a source
signal. Signals can also be calculated in real time.
S MX879B Multi‐I/O module
The module has 8 scalable voltage outputs and 32
configurable digital inputs/outputs. Signals can also be
calculated in real time.
All modules have the following in common:
S Supply voltage range 10 … 30 V DC (nominal rated
voltage 24 V DC)
