Click One-touch Calibraon. When calibraon for all scenes is complete, click
Stop Calibraon to exit.
Single Scene
Calibraon
If certain scenes in panoramic channel have bad stching eect, it is
r
ecommended to use Single Scene Calibraon to calibrate these scenes.
Select a scene. Use the PTZ control buons to adjust the close-up view to the
same scene in the panorama view. Click Single Scene Calibraon, and the
calibraon for the selected scene starts.
When the calibraon is complete, click Stop Calibraon to exit. Select
another scene and repeat the calibraon.
4.
Click Save.
4.13.2 Set Panorama Linkage – Manual Calibraon
Steps
1.
Go to Conguraon → Calibrate → Panorama Linkage .
2.
Select the Calibraon Mode as Manual Calibraon. Click Start Calibraon.
3.
Select a scene.
4.
Add calibraon points.
1) Select a No. in Calibraon Parameter lis
t. Click
.
A number
ed green cross displayed on the live image.
2) Drag the green cross to a certain posion.
3) Repeat the steps above to add more calibraon points.
Note
●
It is r
ecommended to add at least 9 calibraon points in one scene. For higher tracking
precision, up to 12 calibraon points can be added. Calibraon points should be distributed
evenly in live image, for example, 3 points at far range, middle range, and close range each.
●
It is recommended to put calibraon points at disnct posions in live image (for example,
corners). If no disnct posion is available, you can place something (for example, box, stool,
or people) to mark the posion.
5.
Link the P
TZ channel to the calibraon points in panorama view.
1) Select a calibraon point in panorama view.
2) Adjust the PTZ channel to set the center of the close-up view at the same posion as the
calibraon point in panorama view by using the PTZ control buons.
3) Click
to link the current PTZ posions to the
calibraon point.
4) Repeat the steps above to link other calibraon
points.
6.
Click Start Calibraon to nish the calibraon for the current scene.
7.
When calibraon is complete, click Stop Calibraon to exit.
8.
Click Save.
TandemVu PTZ Camera User Manual
26
