Redundancy
RM Web L3E
Release
6.0
07/2010
7.6
VRRP/HiVRRP
217
Figure 51: Tracking dialog
Parameter Meaning
Port Port to which this entry applies, in the form <Slot>.<Port>
VRID Virtual router ID of the assigned virtual router.
Track ID Identification number of the tracking object for which you are
registering this entry (see on page 156 “Applications“).
Track Decrement Change value by which the current VRRP priority of the assigned
VRRP priority is reduced when the tracking object gets the status
“down”.
Status Current status of the tracking object:
“up” or “down”.
Active Entry is displayed as “active” if the tracking object is fully set up and is
activated.
More information on active the entries is available (see on page 217
“Tracking dialog“).
If the entry is not active, its status is “up”.
Table 98: VRRP tracking table
