Hirschmann MACH 4000 Reference Manual

Time
86
3.2 PTP (IEEE 1588)
RM Web
Release 6.0 07/2010
 PTP Version 2 (TC), Global Settings
Parameter Meaning Possible Values Default Setting
Runtime
Measuring
Mechanism
Mechanism for measuring the
message runtime.
Enter the same mechanism for the
PTP device connected to this port.
The device itself does not generate
any messages in the runtime
measurement. A connected PTP
slave measures the runtime of the
entire transmission path to the
master.
E2E (End-to-End):
The device itself measures the
runtime to all the connected PTP
devices. If a reconfiguration is
performed, this eliminates the need
to determine the runtime again.
P2P (peer-to-peer)
Primary Domain Assignment of the
clock to a PTPv2
domain.
0-225
Multi Domain
Mode
TC corrects messages from all
domains.
Yes Yes
TC only corrects messages from the
primary domain.
No
Network
Protocol
Network protocol for P2P and
management messages.
udplpv4
ieee8023
udplpv4
Syntonize Synchronize frequency. Yes
No
No
PTP
Management
Activate/deactivate the PTP
management.
To reduce the load on the device,
deactivate PTP Management and
Syntonize
- at high synchronization rates and
- in Unicast mode.
Yes
No
Yes
Table 27: Function IEEE 1588 / PTPv2 TC
Parameter Meaning Possible Values Default Setting
Clock identifier UUID of the TC (transparent clock)
Current master If Syntonize is enabled, displays the
UUID of the master with which the
device synchronizes its frequency.
Table 28: Status IEEE 1588 / PTPv2 TC
