Time
RM Web L3E
Release
6.0
07/2010
3.2
PTP (IEEE 1588)
87
PTP Version 2 (TC), Port Settings
Parameter Meaning Possible Values Default Setting
Module Module number
for modular devices, otherwise 1.
Port Port to which this entry applies.
If the device does not support the
PTP mode selected, the table is
empty.
PTP on Port sends/receives PTP
synchronization messages
on on
Port blocks PTP synchronization
messages. The device does not
process any PTP messages it
receives at this port.
off
P2P Runtime
Measuring
Interval
Interval for peer-to-peer runtime
measurements at this port.
Prerequisite:
You have selected the P2P runtime
measuring mechanism on the
device itself and on the connected
PTP device.
P2P Runtime Measured P2P (Peer-to-Peer)
runtime. Prerequisite: you have
selected the P2P runtime
measuring mechanism.
Asymmetry Correction of the runtime
asymmetry in ns. A runtime
measurement value of x ns
corrupted by asymmetrical
transmission values corresponds to
an asymmetry of x·2 ns
Table 29: Port Dialog Version 2(TC)
