Fluent Pro Fluid Management System
English Introduction 9
1.3.3.4 In-FloPak Lever
The In-FloPak Lever is intended to hold the In-FloPak
TM
in place as well as aid in the release of the In-FloPak
during disassembly.
1.3.3.5 Out-FloPak Lever
The Out-FloPak Lever is intended to hold the Out-FloPak
TM
in place as well as aid in the release of the Out-
FloPak during disassembly.
1.3.3.6 MyoSure TRD Panel
1.3.3.6.1 MyoSure Tissue Removal Device (TRD) Connector
The MyoSure tissue removal device (TRD) Connector is located on the Fluent Pro Fluid
Management System front panel above the Foot Pedal Connector. For details on operating the
Tissue removal device, refer to MyoSure tissue removal device Instructions for Use.
1.3.3.6.2 Foot Pedal Connector
The Foot Pedal Connector is located on the Fluent Pro Fluid Management System front panel
below the MyoSure tissue removal device (TRD) Connector.
1.3.3.7 Waste Bag Hooks
Location to hang the 6L Waste Bag.
WARNING!
Do not place excessive force or weight on the Waste Bag Hooks. Doing so may result in an inaccurate fluid
deficit value, causing risk to patient safety.
1.3.3.8 Wheels
The four wheels located on the bottom of the Fluent Pro Fluid Management System enable movement and
positioning of the Fluent Pro Fluid Management System.
1.3.3.9 Wheel Lock
A wheel lock is available on each of the four wheels. For details on using the wheel locks, see Instructions
provided in Section 2.
1.3.3.10 Power Button
The Power button is located on the top of the Fluent Pro Fluid Management System.
1.3.3.11 IV Pole
Pole located next to the Touchscreen Monitor that contains two Fluid Bag Hooks.
1.3.3.12 Power Cord Port
The Power Cord Port is located on the rear of the Fluent Pro Fluid Management System. The Power Cord
attaches to the Power Cord Port. When the system is not in use, wrap the Power Cord around the Cord Wrap
on the rear of the system.
