P/N MAN-01964 Revision 001 21
DRAFT
Preview copy—Generated 7/9/2010
User Manual
Chapter 2—System Controls and Indicators
Perform the Functional Tests
C-arm Rotation Switch Push the C-arm Rotation switch away from you to move the
C-arm toward you.
Pull the C-arm Rotation switch toward you to move the
C-arm away.
The C-arm movement stops when the switch is released.
Table 2-1: C-arm Functional Tests
Function Functional Test
