20 P/N MAN-01964 Revision 001
DRAFT Preview copy—Generated 7/9/2010
User Manual
Chapter 2—System Controls and Indicators
Perform the Functional Tests
Counterclockwise C-arm
Rotation
Press the Counterclockwise C-arm Rotation to start
counterclockwise C-arm rotation.
Left Panel Right Panel
Clockwise C-arm Rotation Press the Clockwise C-arm Rotation button to start
clockwise C-arm rotation.
Left Panel Right Panel
Table 2-1: C-arm Functional Tests
Function Functional Test
