P/N MAN-01964 Revision 001 19
DRAFT
Preview copy—Generated 7/9/2010
User Manual
Chapter 2—System Controls and Indicators
Perform the Functional Tests
C-arm Down Press the C-arm Down button:
• The C-arm movement automatically stops when the
button is released.
• The C-arm movement automatically stops when the
C-arm reaches the lower travel limit.
• The C-arm movement is disabled when a compression
force of 45 N (10 pounds) or greater is applied.
Table 2-1: C-arm Functional Tests
Function Functional Test
