2. Remove power from the server blade in one of the following ways:
• Use the iLO 2 Virtual Power Button on the Remote Console to power off the server blade
from a remote location. It can take up to 30 seconds for the server blade enter standby
mode. Wait for the power LED to change from green to amber before proceeding.
• Press the power button on the front of the server blade. It can take up to 30 seconds for
the server blade to reach standby. Wait for the power LED to change from green to amber
before proceeding.
Removing and Replacing the Server Blade from the Enclosure
Use the following procedures to remove and replace the server blade from the enclosure.
Removing the Server Blade from the Enclosure
To remove the server blade from the enclosure:
1. Press the release button on the server blade (1).
See Figure 41.
CAUTION: After you press the release button, the server blade is unlocked from the enclosure.
Use both hands to support the server blade when you remove it from the rack. The server
blade weighs approximately 17 kg (38 lb).
The enclosure fans might still be running when the server blade is in standby mode. Opening
the lever removes all power from the server blade.
2. Open the lever (2).
3. Grasp the lever and slide the server blade out of the enclosure (3), placing your hand under
the server blade to support it while removing it from the enclosure.
114 Removing and Replacing Components
