Figure 6 SAS Disk Drive LEDs
21
Status LEDActivity LED
For troubleshooting information regarding the SAS disk drive LEDs, see “SAS Disk Drive LEDs
(page 96).
SUV Cable and Ports
The HP Integrity BL870c server blade has an SUV cable port that accepts the SUV cable. Use the
SUV cable to connect the server to external devices, such as a terminal emulator, an external DVD
drive, or a monitor. The SUV cable attaches to the front of the server blade in the SUV cable port.
Figure 7 shows the SUV cable.
CAUTION: The SUV cable is not designed to be used as a permanent connection.
Use caution when the SUV cable is installed on the server blade. Hitting or bumping the cable can
cause the port on the server blade to break. This can damage the system board, which will then
need to be replaced.
22 Overview
