HP Integrity BL870c User's & Service Guide

A Parts Information
This appendix provides parts information for the HP Integrity BL870c server blade components
(customer replaceable units [CRUs]).
Server Blade Components List
Table 28 details the part numbers of the components (or CRUs) in the server blade.
NOTE: Part numbers are found by using the part nomenclature from this list to select the correct
part from the HP Partsurfer. If a part that is not listed in the CRU list needs to be replaced, the Base
Unit Repair Kit is required.
Table 28 CRU List
Replacement Part
Number
Manufacturing Part
Number
Description
Memory
AB564-69002AB564BX1 GB DDR2 memory
AB565-69002AB565BX2 GB DDR2 memory
AB566-69002AB566BX4 GB DDR2 memory
AB567-69001AB567AX8 GB DDR2 memory
Processors
AD394-2101CAD394-2101CItanium CPU 1.4 GHz 12 MB dual core
AH255-2101CAH255-2101CItanium CPU 1.6 GHz 18 MB dual core
AH320-2101CAH320-2101CItanium CPU 1.67 GHz 24 MB dual core
Internal Disks
432322-001418373-00536 GB, 15k RPM SAS hot-plug disk
376597-001375863-00272 GB, 10k RPM SAS hot-plug disk
432321-001418373-00772 GB, 15k RPM SAS hot-plug disk
432320-001375863-011146 GB, 10k RPM SAS hot-plug disk
Boards and Cards
AH232-69101AH232-60001BL870c system board
AH232-6900AAH232-60002BL870c memory mezzanine
AH232-6706AAH232-60003BL870c 4 disk drive SAS backplane
AH232-6707A6070B0227401Disk drive carrier / front panel with logo
405920-001404986-001QLogic QMH2462 4 GB FC HBA
410500-001406855-0014x DDR Mellanox MT25204 InfiniBand
448066-001447881-001NC364m 4 port NIC
Cables
409496-001409496-001Local I/O cable (SUV)
AH232-6703ACPU MVR cable
439329-001438806-001SAS cable
Server Blade Components List 143
