Automation and remote LED connector
The combined Automation and Remote LED Connector is a 16-pin wafer surface-mount right-angle
connector. 10 pins are used for the ACI/ADI interface and 6 pins for the remote LEDs.
Connector pins
ACI operation
When used for ACI communications, the pins of the ACI connector are as follows:
FunctionIDPin
RS-422 Receive (+ side of the differential RS-422 line)
ACI_RX+
1
RS-422 Receive (– side of the differential RS-422 line)
ACI_RX-
2
Ground
GND
3
RS-422 Transmit (– side of the differential RS-422 line)
ACI_TX-
4
RS-422 Transmit (+ side of the differential RS-422 line)
ACI_TX+
5
Drive Sense. It is tied low in the drive so that a library can sense the presence of
the drive. The library should have a pull-up resistor on this line.
Low: Drive present
High: Drive not present (3.3 volts)
ACI_DRV_SEN_L6
Library Sense. The drive will not appear on the bus until commanded when low.
The line is pulled up to 5V in the tape drive. The automation controller should pull
this pin low.
Low: Drive is connected to an automation controller
High: Drive is standalone (3.3 volts)
ACI_LIB_SEN_L7
Tape drive reset. The line is pulled up to 3.3V in the drive. The drive will perform
a Drive Reset when this line is pulled low.
ACI_RST_L
8
The drive sets this pin low to indicate to the automation controller that certain
configured conditions have arisen, such as a SCSI Surrogate CDB.
ACI_ATN_L
9
No connection—10
Supported Baud rates
NotesBaud Rate
Default rate9600
19200
38400
57600
115200
Volume 1: hardware integration 37

HP LTO Ultrium Specifications

General

Category	Tape Drive
Capacity (Compressed)	Up to 30 TB (LTO-8), Up to 45 TB (LTO-9)
Transfer Rate (Compressed)	Up to 900 MB/s (LTO-8), Up to 1000 MB/s (LTO-9)
Interface	SAS, Fibre Channel
Technology	Linear Tape-Open (LTO)
WORM Support	Yes
Encryption Support	Yes (AES 256-bit)
Partitioning Support	Yes
Capacity (Native)	Up to 12 TB (LTO-8), Up to 18 TB (LTO-9)
Transfer Rate (Native)	Up to 360 MB/s (LTO-8), Up to 400 MB/s (LTO-9)
Backward Read Compatibility	Yes (LTO-8 reads LTO-7, LTO-6; LTO-9 reads LTO-8, LTO-7)
Backward Write Compatibility	Yes (LTO-8 writes to LTO-7; LTO-9 writes to LTO-8)
