HP MR Gen10 Plus User Manual

Enabling Drive SecurityEnabling Drive Security
ProcedureProcedure
1. From the System Utilities screen, select System Configuration > HPE MRXXX Gen10+ > Main Menu > Controller Management.
2. In the Controller Management screen, select Advanced Controller Management.
3. In the Advanced Controller Management screen, select Enable Drive Security .
4. For the Key Management Mode, select either Local Key Management (LKM) or External Key Management (EKM) .
5. Optional. If you have selected Local Key Management (LKM), do the following:
a. Enter the required data on the screen. You are allowed to set the Security Key Identifier , Security Key, and Password at Boot
Time.
b. Select the I Recorded the Security Settings for Future Reference check box.
c. Click Enable Drive Security .
6. Optional. If you have selected External Key Management (EKM) , do the following:
a. Make sure that the iLO key manager is properly configured only then you can select External Key Management (EKM) . For more
information, see "Using Enterprise Secure Key Manager with iLO" in the HPE iLO 5 User GuideHPE iLO 5 User Guide.
b. Click Enable Drive Security .
c. Reboot the system.
The controller retrieves the SED drive keys from the remote HPE Enterprise Secure Key Manager server only during power-up. It
communicates to iLO through the BIOS.
Enabling Drive Security 123

HP MR Gen10 Plus Specifications

General

Device Type	RAID Controller
Interface	PCIe 3.0 x8
RAID Support	Yes
Category	Controller
RAID Levels	0, 1, 5, 6, 10, 50, 60
Memory	2GB Flash-backed cache
Storage	SAS/SATA
Power Supply	Not Applicable
