HP MR Gen10 Plus - Erasing a Logical Drive

Erasing a logical driveErasing a logical drive
ProcedureProcedure
1. From the System Utilities screen, select System Configuration > HPE MRXXX Gen10+ > Main Menu > Logical Drive Management.
2. In the Logical Drive Management screen, select the logical drive.
3. In the Logical Drive screen, select Logical Drive Erase from the Operation drop-down menu.
4. Select one of the following options from the Erase Mode drop-down menu:
Simple - Writes a pattern to the logical drive in a single pass.
Normal - A three-pass operation that first overwrites the drive contents with random values then overwrites it twice with
patterns.
Thorough - Repeats the Normal drive erase operation three times.
5. If you want to delete the logical drive after the erase is completed, click Delete After Erase .
6. Click Go.
7. Review warning messages and click Confirm and Yes to proceed.
Erasing a logical drive 142
