7-2
Using the OmniBook Docking Solutions
The OmniBook Docking Solutions provide external connections for the
OmniBook that you can leave in place whenever you remove the
OmniBook from your desk. Instead of disconnecting and reconnecting
peripheral devices, simply undock and dock the OmniBook. There are
three docking solutions to choose from.
The OmniBook Port Replicator provides an inexpensive way to easily
connect your Monitor, Keyboard, Mouse and printer. The Port replicator
features the following:
• Parallel Port (supports EPP/ECP and floppy drive).
• Serial Port (115,200-bps).
• Video port.
• External keyboard connector.
• External PS/2 mouse connector.
• Three audio jacks for Speaker-out, Line-in, and Microphone-in.
• AC adapter jack.
• 2 universal serial bus (USB) ports.
• 60W AC adapter included.
The OmniBook Mini Dock provides all the same features of the Port
Replicator but adds the following:
• Two Type III PC Card slots with CardBus support. (PC Card Eject
Lock)
The OmniBook Docking System provides full desktop replacement. It
includes all the features of the Mini Dock plus the following:
• 2 half-height PCI Slots
• Built-in SCSI 2
• 5 ¼” half-height desktop expansion bay (supports SCSI and IDE)
• Notebook module bay (requires Dock module bay adapter)
You can lock down all devices inserted into the Dock (such as PCI Cards,
PC Cards, notebook module) when a Kensington Lock in connected to the
Dock.
