Smart Array 102
4-4-5 HPSA_StorageVolumeIndication: Logical Drive
Status Changed to OK
Table 4-99 HPSA_StorageVolumeIndication : Logical Drive Status Changed to OK
Property name Property implementation
ImpactedDomain 3 (Enclosure) for c-Class blade systems
4 (System) for all other systems
NOTE: When ImpactedDomain is 3 (Enclosure) the
properties indicated with (*) are populated.
BladeBay * HP_BladeCSLocation.LocationInformation[0]
BladeName * HP_ComputerSystem.Name
EnclosureName * HP_BladeEnclosureCS.Name
RackName * Rack name if one exists
RackUID * Rack Unique Identifier if one exists
SystemVirtualSerialNumber Conditional property containing the virtual system
serial number string when running in a Virtual Connect
environment
SystemVirtualUUID Conditional property containing the virtual system
UUID when running in a Virtual Connect environment
HP_HardwareIndication
HWLogicalLocation Logical drive number and RAID level. For example,
LogicalDrive 1 (RAID 1+0)
VariableNames FailureDescription
VariableTypes String (1)
VariableValues FailureDescription-short description of the failure
HP_DeviceIndication
HPSA_StorageVolumeIndication
DeviceOperationalStatus Current OperationalStatus values for Storage Volume
DeviceOperationalStatus[0]:
SMX_SAStorageVolume.OperationalStatus[0]
DeviceOperationalStatus[1]:
SMX_SAStorageVolume.OperationalStatus[1] (This
index is only populated if there is additional Vendor
unique status available)
DeviceOperationalStatusPrevious Previous OperationalStatus values for Storage Volume
DeviceOperationalStatusPrevious[0]:
SMX_SAStorageVolume.OperationalStatus[0]
DeviceOperationalStatusPrevious[1]:
SMX_SAStorageVolume.OperationalStatus[1] (This
index is only populated if there is additional Vendor
unique status available)
