Ethernet port 18
Table 2-3 Class: SMX_EthernetDevice
Property name Property implementation
HP_EthernetDevice
GroupComponent ref: SMX_ComputerSystem (the computer system in
which this Ethernet Port resides)
PartComponent ref: SMX_EthernetPort (the instance of Ethernet Port in
this ComputerSystem)
2-3-3 SMX_EthernetLANEndpoint
SMX_EthernetLANEndpoint implements the class HP_EthernetLANEndpoint and describes a
communication endpoint which, when its associate interface is connected to a LAN, might send and
receive data frame.
Table 2-4
Class: SMX_EthernetLANEndpoint
Property name Property implementation
CIM_ManagedElement
Caption LAN Endpoint info for OS Exposed Ethernet Port
informatiom. For example:
LAN Endpoint(<instanceNum>) for : 82546GB Gigabit
Ethernet Controller port <portNumber>
CIM_ManagedSystemElement
HealthState 5 (OK), normal operation
20 (Major Failure)
Name HPQ:SMX_EthernetLANEndpoint:<instanceNum>
OperationalStatus 0 (Unknown)
2 (OK)
3 (Degraded)—Indicating that there is no link for this
Port
6 (Error)—Indicating that previous active link lost
connectivity
StatusDescriptions StatusDescriptions[0] per OperationalStatus[0]:
•
Unknown
•
OK
•
Degraded
•
Error
CIM_LogicalElement
CIM_EnabledLogicalElement
CIM_ServiceAccessPoint
CreationClassName SMX_EthernetLANEndpoint
SystemName SMX_ComputerSystem.Name
