PCI Device Provider 38
3 PCI Device Provider
3-1 Overview
This provider implements the profiles listed to support PCI devices installed in HP servers.
The following table details the profiles implemented and files installed by this provider.
Table 3-1
Overview
Implemented Profiles
•
DMTF: PCI Device Profile (DSP1075) 1.0.0a
09/2007
•
DMTF: Physical Asset Profile
•
HP: Location Profile 1.0
3-2 Use Cases
See DMTF PCI Device Profile for Use Cases.
3-3 Class Implementations
The following classes and properties are implemented as specified in the following tables for HP
Server platforms where available. The classes below describe PCI Device.
3-3-1 SMX_PCIDevice
SMX_PCIDevice is used to model PCI devices on HP Servers. There is an instance of this class for each
logical PCI device present in the system.
Table 3-2
Class: SMX_PCIDevice
Property name
Property implementation
CIM_ManagedElement
Caption A user-friendly description for this PCI device provided
by the operating system
Description A user-friendly description for this PCI device provided
by the operating system
ElementName A hardware ID for this PCI device provided by the
operating system
CIM_ManagedSystemElement
Name A hardware ID for this PCI device provided by the
operating system
CIM_LogicalDevice
