Smart Array 95
4-4-2 HP_DeviceIndication: Physical Drive Status
Changed to ERROR
Table 4-96 HP_DeviceIndication: Physical Drive Status Changed to ERROR
Property name Property implementation
SystemVirtualUUID Conditional property containing the virtual system
UUID when running in a Virtual Connect environment
HP_HardwareIndication
HWFirmwareVersion Physical Disk F/W version string
HWLogicalLocation Physical Disk Location string
For exmaple, Port:1E Box: 1 Bay 5
HWPhysicalLocation Physical Location of the Failed Drive (Bay Number)
HWSerialNumber Physical Disk Serial Number
VariableNames[] FailureDescription
DriveInterface
VariableTypes[] String (1)
uint16 (4)
VariableValues[] FailureDescription short description of the failure
Drive interface HPSA_DiskDrive.DriveInterface
LastFailureDescription – last failure reason string from
the drive. HPSA_DiskDrive.OperationalStatus[1]
HP_DeviceIndication
DeviceModel Physical Disk Model string
DeviceControllerLogicalLocation Controller Location
For example, SmartArray 642 in Slot 2, Smart Array
P400 Embedded Controller=7” for embedded
controller where 7 is the internal identifier for the
embedded controller
4-4-3 HP_DeviceIndication: Physical Drive Status
Changed to REBUILDING
Table 4-97 HP_DeviceIndication: Physical Drive Status Changed to REBUILDING
CIM_Indication
IndicationIdentifier GUID string generated at the time of indication
PerceivedSeverity 2 (Informational)
