System Temperature Sensor 318
12 System Temperature Sensor
12-1 Overview
This provider implements the HP Sensor Profile to model temperature sensors in ProLiant servers.
The following table details the profiles implemented and files installed by this provider.
Table 11-1
Overview
Implemented Profiles HP Sensor Profile 1.0
12-2 Use cases
See HP Sensor Profile for Use Cases.
12-2-1 Class implementations
The following classes and properties are implemented as specified in the following tables for server
platforms where available. The classes below describe temperature sensors.
• SMX_NumericSensor
• SMX_SensorCollection
• SMX_SystemSensor
• SMX_HostedSensorCollection
• SMX_MemberOfSensorCollection
12-2-2 SMX_NumericSensor
SMX_NumericSensor implements HP_NumericSensor and is used to model temperature sensors on
Servers.
Table 11-2
Class: SMX_NumericSensor
CIM_ManagedElement
Caption Temperature Sensor <sensorID>, where <sensorID> is
the name displayed by iLO. For example, Temperature
Sensor Temp 1.
Description Temperature Sensor <sensorID> detects for
NumericSensorType. StatusDescription where
<sensorID> is the name displayed by the MP or iLO.,
NumericSensorType represents the value of
NumericSensorType and StatusDescription represents
the value of StatusDescriptions[0]
