Smart Array 59
Table 4-13 Class: SMX_SAPortController (CIM_PortController)
Property name
Property implementation
CIM_LogicalDevice
CreationClassName SMX_SAPortController
DeviceID Controller serial number
SystemCreationClassName SMX_SAArraySystem
SystemName SMX_SAArraySystem.Name
CIM_Controller
CIM_PortController
ControllerType 1 (Other)
OtherControllerType SCSI – Parallel SCSI HBA
SAS/SATA – SAS/SATA HBA
HPSA_PortController
4-3-13 SMX_SADAPort
SMX_SADAPort implements the HPSA_DAPort class and represents the front-end port for an HBA in
the host system. Direct Attached implies that the array controller is attached to a local bus on the host
(for example, PCI).
Table 4-14
Class: SMX_SADAPort (CIM_DAport)
Property name Property implementation
CIM_ManagedElement
ElementName Controller name and location
Smart Array in Slot=3
Smart Array Embedded Controller =7 embedded
controller where 7 is the internal indntifier for the
embedded controller
CIM_ManagedSystemElement
OperationalStatus[0] Port status:
•
0 (Unknown)
•
2 (OK)
•
6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
EnabledState 5 (Not applicable)
RequestedState 12 (Not applicable)
CIM_LogicalDevice
