Smart Array 71
Table 4-28 Class: SMX_SAArraySystemLocation (HP_Location)
Property name
Property implementation
LocationInformation[0] For internal HBAs: PCI Slot number
Examples:
•
3—PCI Slot 3
•
0—Embedded on Motherboard
Not Required for External Storage systems
LocationInfoDesc[0] 3 (PCI Slot)—For internal HBAs
Not required for External Storage Systems
HPSA_ArraySystemLocation
4-3-28 SMX_SADiskDriveLocation
SMX_SADiskDriveLocation implements the HPSA_DiskDriveLocation class and represents a location
string for the disk drive.
Table 4-29
Class: SMX_SADiskDriveLocation (HP_Location)
Property name
Property implementation
CIM_ManagedElement
Caption Controller name, Drive Type and Disk Location
For example, Smart Array E500 Physical Drive – Port:
1E Box 1 Bay: 5
Description Controller name, Drive Type and Disk Location
For example, Smart Array E500 Physical Drive – Port:
1E Box 1 Bay: 5
ElementName Controller name, Drive Type and Disk Location
For example, Smart Array E500 Physical Drive – Port:
1E Box 1 Bay: 5
CIM_Location
Name Opaque key
PhysicalPosition Opaque key
HP_Location
ElementLocationTag Bay Number of Disk Drive— When Bay is specified in
ElementLocationTagDesc.
ElementLocationTagDesc 20 (Bay)—When firmware supports Bay numbering
HPSA_DiskDriveLocation
4-3-29 SMX_SAArrayControllerLocation
SMX_SAArrayControllerLocation implements the HPSA_ArrayControllerLocation class and represents a
location string for the array controller.
