Smart Array 69
Table 4-26 Class: SMX_StorageSpecificCollection (HP_GroupHostedCollection)
Property name
Property implementation
Caption Storage Array Consolidated Status
Description Storage Array Consolidated Status
ElementName Storage Array Consolidated Status
CIM_Collection
CIM_SystemSpecificCollection
InstanceID
Opaque key
HP_GroupSystemSpecificCollection
GroupOperationalStatus[0] Consolidated status for all array controllers. See
section 9.10 Consolidated status example of HP Smart
Array profile for details on how this value is calculated.
GroupStatusDescriptions[0] Description of failure
HPSA_StorageSpecificCollection
4-3-26 SMX_SADriveCageLocation
SMX_SADriveCageLocation implements the HPSA_DriveCageLocation class and represents a location
string for the drive cage.
Table 4-27
Class: SMX_SADriveCageLocation (HP_Location)
Property name Property implementation
CIM_ManagedElement
Caption Drive Cage
Description Drive Cage
ElementName Drive Cage
CIM_Location
Name Opaque key
PhysicalPosition Opaque key
HP_Location
ElementLocationTag Duplex Top, Duplex Bottom, Non Duplex
ElementLocationTagDesc 22 (Drive Cage)
LocationInformation[0] HBA Port identifier
Examples:
•
J3
•
2I
•
1E
LocationInfoDesc[0] Port
