Smart Array 65
4-3-20 SMX_SADriveCage
SMX_SADriveCage implements the HPSA_DriveCage class and represents the drive cage assembly
and backplane within a storage enclosure. Multiple instances might occur within a duplexed
enclosure.
Table 4-21
Class: SMX_SADriveCage (CIM_PhysicalPackage)
Property name
Property implementation
CIM_ManagedElement
ElementName Port <n>, where <n> is the name of the port this drive
cage is connected
For example, Port J3
CIM_ManagedSystemElement
Name Serial Number of drive cage
N/A—When serial number is not available
CIM_PhysicalElement
CreationClassName SMX_SADriveCage
Manufacturer
Drive Cage Vendor string
Model Drive Cage Model string
PartNumber N/A—Not available in this implementation
Tag Opaque key
SerialNumber Enclosure Serial number
Version N/A—Not available in this implementation
CIM_PhysicalPackage
RemovalConditions 2 (Not Applicable)
HP_DriveCage
BackplaneSpeed
See HP Smart Array Profile
DriveBays See HP Smart Array Profile
DuplexLocation See HP Smart Array Profile
HPSA_DriveCage
4-3-21 SMX_SASCSIProtocolEndpoint
SMX_SASCSIProtocolEndpoint implements the HPSA_SCSIProtocolEndpoint class and represents an
access point to storage resources.
Table 4-22
Class: SMX_SASCSIProtocolEndpoint (CIM_SCSIProtocolEndpoint)
Property name Property implementation
CIM_ManagedElement
