System Fan 274
Table 9-10 Class: SMX_FanLocation
Property name
Property implementation
Description Description of the fan location including the name
displayed by the MP or iLO.
For example: The location of the fan Fan 1. Please
refer to the fan position CabinetFan=01 printed on the
system.
ElementName User displayable name of the fan location including the
name displayed by the MP or iLO.
For example: Fan 1 at CabinetFan=01
CIM_Location
Name Unique identifier for this fan location instance
PhysicalPosition
Opaque identifier for the physical position of this fan
HP_Location
ElementLocationTag Location string based on
ElementLocationTagDescription. For example, on
ProLiant CabinetFan=01.
ElementLocationTagDesc On ProLiant: 0 (HoodTag)
LocationInfoDesc Array of location descriptions:On ProLiant: 4 (Socket)
LocationInformation Array of string representions of the location based on
LocationInfoDesc.
9-3-10 SMX_FanElementLocation
SMX_FanElementLocation is used to represent an association between CIM_Location and
CIM_ManagedElement.
Table 9-11
Class: SMX_FanElementLocation
Property name Property implementation
Element References CIM_ManagedElement
PhysicalLocation References CIM_Location
9-3-11 SMX_FanModule
SMX_FanModule is used to model physical fans on Servers. Please note: Fan numbers for existing
instances do not change when other fans are added and removed.
Table 9-12
Class: SMX_FanModule
Property name Property implementation
CIM_ManagedElement
