ElementName Controller name and location (for example, Smart
Array in Slot=3, or Smart Array Embedded
Controller=7 for embedded controller where 7 is the
internal identifier for the embedded controller )
CIM_ManagedSystemElement
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault 2 (Enabled)
RequestedState 12 (Not Applicable)
CIM_ServiceAccessPoint
CreationClassName SMX_SASCSIProtocolEndpoint
Name HBA Serial Number
SystemCreationClassName SMX_SAArraySystem
SystemName SMX_SAArraySystem.Name
CIM_ProtocolEndpoint
ProtocolIFType 1(Other)
OtherTypeDescription SCSI
CIM_SCSIProtocolEndpoint
ConnectionType 1 (Other)
OtherConnectionType PCI
Role 0 (Unknown)
2 (Initiator)
3 (Target)
4 (Both Initiator and Target)
HPSA_SCSIProtocolEndpoint
4-3-22 SMX_SASCSIProtocolController
SMX_SASCSIProtocolController implements the HPSA_SCSIProtocolController class and represents a
view a SCSI resources on the Array Controller.
Table 4-23
Class: SMX_SASCSIProtocolController (CIM_SCSIProtocolController)
Property name Property implementation
CIM_ManagedElement
ElementName Controller name and location (for example, Smart
Array in Slot=3, Smart Array Embedded Controller=7
for embedded controller where 7 is the internal
identifier for the embedded controller)
