8-3-17 SMX_ProcessorLocation
SMX_ProcessorLocation implements the class HP_Location which extends the class CIM_Location.
For ProLiant systems, processor location is denoted by the use of a slot number designator and a
socket number designator. Either value might be zero, depending on the system:
• On older ProLiant systems, the processors are mounted on processor boards that fit in slots in the
system. The slot number designator indicates the processor board slot where the processor is
located. A socket number designator value of zero indicates one processor is mounted on a
processor board. A nonzero socket number designator indicates the multiple processor board
sockets where a processor is located.
• On modern ProLiant systems, processors are mounted in sockets on the system board. When the
slot number designator is zero, the processors are located on the system board
The following properties are implemented.
Table 8-18
Class: SMX_ProcessorLocation
Property name Property implementation
CIM_ManagedElement
Caption Processor in ProcesssorBoard=a, where a is the slot
number
Processor in CPUSocket=b, on System MainBoard
where b is the socket number
Processor in CPUSocket=b on Processorboard=a,
where a is the slot number and b is the socket number
Description <processor brand string> (x86 Family x Model y
Stepping z), where <processor brand string> is the
processor brand string, x is the processor family
number, y is the processor model number and z is the
processor stepping number
Example: Intel(R) Xeon(TM) 3.06GHz (x86 Family 15
Model 2 Stepping 7)
