Smart Array 76
Table 4-34 Class: Class: SMX_SATSASPort (HPSA_TSASPort)
Property name
Property implementation
PortType 94 (SAS)
HPSA_SAISASPort
4-3-34 SMX_SATSASSCSIProtocolEndpoint
SMX_SATSASSCSIProtocolEndpointPort implements the HPSA_TSASSCSIProtocolEndpoint class and
represents an access point to storage resources.
Table 4-35
Class: SMX_SATSASSCSIProtocolEndpoitPort (HPSA_TSASSCSIProtocolEndpoint)
Property name
Property implementation
ElementName Protocol Endpoint for xxx, where xxx is the value
populated in the caption property of the instance of
HPSA_TSASPort associated to this instance through the
association HPSA_TSASPortTSASSCSIPE
Caption Protocol Endpoint for xxx, where xxx is the value
populated in the caption property of the instance of
HPSA_TSASPort associated to this instance through the
association HPSA_TSASPortTSASSCSIPE
EnabledDefault 2 (Enabled
RequestedState 12 (Not Applicable)
CreationClassName “SMX_SATSASSCSIProtocolEndpoint”
SystemCreationClassName “SMX_SAArraySystem”
SystemName SMX_SAArraySystem.Name
ProtocolIFType 1 (Other)
OtherTypeDescription “SCSI”
Role 3 (Target)
HPSA_SATSASSCSIProtocolEndpoint
4-3-35 SMX_SAISASPort
SMX_SAISASPort implements the HPSA_ISASPort class and represents the initiator port for the HBA.
Table 4-36
Class: Class: SMX_SAISASPort (HPSA_ISASPort)
Property name Property implementation
ElementName Port: port m
where
<
m
>
is the port number
Caption Port: port m
where
<
m
>
is the port number
