Smart Array View Class 152
5 Smart Array View Class
5-1 Overview
The HP Smart Array View Class data sheet describes host based Smart Array HBA’s and the attached
devices. The current View Class implementation does not support externally attached Smart Array
based MSA devices. For example, MSA500, or MSA20.
5-2 Class Implementations
5-2-1 HPVC_SAController
HPVC_SAController represents the Smart Array HBA. There will be one instance per HBA.
Table 5-1
Class: HPVC_SAController
ElementName Controller product name and controller index
For example, HP Smart Array P400 Controller : HPSA1
Note: Each Smart Array controller should have a
unique controller index. Index is an integer that starts
from 1.
HealthState 0 (Unknown)
5 (OK)
10 (Degraded/Warning)
15 (Minor Failure)
20 (Major Failure)
25 (Critical Failure)
30 (Non-recoverable Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
CIM_System
CreationClassName HPVC_SAController
Name vmwControllerX
Note: VMware Virtual Infrastructure Client requires the
name to be vmwControllerX, where X can be any
string. In our case, string X should match the controller
name reported in HPVC_SAControllerElementName.
For example, vmwControllerHPSA1
CIM_ComputerSystem
