HP ProLiant BL280c - G6 Server - Smx_Memberoffanredundancy; Smx_Hostedfanredundancyset

System Fan 272
Table 9-4 Class: SMX_FanRedundancySet
Property name
Property implementation
InstanceID Unique identifier for this cooling redundancy instance
CIM_RedundancySet
MaxNumberSupported Represents the maximum number of fans supported for
this redundancy set
MinNumberNeeded Represents the minimum number of fans needed to
function
TypeOfSet 3 (Load Balanced)
LoadBalanceAlgorithm 0 (Unknown)
RedundancyStatus 0 (Unknown)—if the redundancy status is unknown
2 (Fully Redundant)—if the all fans in the set are
operating properly and enough to achieve redundancy
3 (Degraded Redundancy)—if there are at least
enough fans for the redundancy set to provide cooling,
but fans have failed
4 (Redundancy Lost)—if there are not enough fans
required to achieve redundancy, but enough for the
redundancy set to provide cooling
5 (Overall Failure)—if there are not enough fans
operating properly for the redundancy set to provide
cooling.
9-3-4 SMX_MemberOfFanRedundancy
SMX_MemberOfFanRedundancy is used to represent an association between HP_Fan and
HP_FanRedundancySet.
Table 9-5
Class: SMX_MemberOfFanRedundancy
Property name Property implementation
Collection References HP_FanRedundancy
Member References HP_Fan
9-3-5 SMX_HostedFanRedundancySet
SMX_HostedFanRedundancySet is used to represent an association between HP_FanRedundancySet
and the computer system that contains this redundancy set.
Table 9-6
Class: SMX_HostedCoolingRedundancySet
Property name
Property implementation
OwningElement References HP_ComputerSystem
OwnedElement References HP_FanRedundancy
