Smart Array 46
4 Smart Array
4-1 Overview
The HP Smart Array data sheet describes both host based Smart Array HBAs and externally attached
MSA enclosures, such as MSA60/70.
NOTE: This provider excludes externally attached MSA controllers, such as MSA500 and fibre
attached devices, for example MSA1000 or MSA
The following profiles are implemented, and the following files are installed by this provider.
Table 4-1
Overview
Profile name Organization Version
HP Smart Array Profile (P00121) HP WBEM TC 1.0.0
4-2 Use cases
For use cases, see the HP Smart Array Profile (P00121).
This provider implements a read-only version of the profiles referenced. Configuration functionality is
not supported by this provider. This is in accordance with the SNIA profiles, because HP does not
advertise and ConfigurationService type classes.
4-3 Class implementations
The following sections define the supported properties for the Smart Array provider. Details for each
property can be found in the HP Smart Array profile (P00121) and associated MOF file.
4-3-1 SMX_SAArraySystem
SMX_SAArraySystem implements the HPSA_ArraySystem class and represents the top level system.
There is one instance per HBA.
Table 4-2
Class: SMX_SAArraySystem (CIM_ComputerSystem)
Property name Property implementation
CIM_ManagedElement
