Ethernet port 19
Table 2-4 Class: SMX_EthernetLANEndpoint
SystemCreationClassName SMX_ComputerSystem
CIM_ProtocolEndpoint
Description Text representing of what the operating system labels
this endpoint.
For example:
eth3
On Windows operating systems:
Local Area Connection 2
ElementName LAN Endpoint info for OS Exposed Ethernet Port
informatiom. For example:
LAN Endpoint(<instanceNum>) for : 82546GB Gigabit
Ethernet Controller port <portNumber>
ProtocolIFType 6 (Ethernet CSMA/CD)
MACAddress Text representing the principal unicast address used in
communication with the LANEndpoint. Twelve
hexadecimal digits. For Example: 010203040506
HP_EthernetLANEndpoint
2-3-4 SMX_EthernetLANHostedAccessPoint
SMX_EthernetLANHostedAccessPoint implements the class HP_EthernetLANHostedAccessPoint and
associates Ethernet LAN Endpoint to the Computer System in a managed system.
Table 2-5
Class: SMX_EthernetLANHostedAccessPoint
Property name Property implementation
CIM_Dependency
CIM_HostedDependency
CIM_HostedAccessPoint
HP_EthernetLANHostedAccessPoint
Antecedent ref: SMX_ComputerSystem
Dependent ref: SMX_EthernetLANEndpoint
2-3-5 SMX_EthernetPortToLANEndpoint
SMX_EthernetPortToLANEndpoint implements the class HP_EthernetPortToLANEndpoint and associates
the Ethernet Port instance to its Ethernet LAN Endpoint instance.
