Smart Array 72
Table 4-30 Class: SMX_SArrayControllerLocation (HP_Location)
Property name
Property implementation
CIM_ManagedElement
Caption Controller name and location
Examples:
•
Smart Array in Slot=3, for internal
•
Smart Array Embedded Controller=7 for embedded
controller where 7 is the internal identifier for the
embedded controller
Description Controller name and location
Examples:
•
Smart Array in Slot=3, for internal
•
Smart Array Embedded Controller=7 for embedded
controller where 7 is the internal identifier for the
embedded controller
ElementName Controller name and location
Examples:
•
Smart Array in Slot=3, for internal
•
Smart Array Embedded Controller=7 for embedded
controller where 7 is the internal identifier for the
embedded controller
CIM_Location
Name Opaque key
PhysicalPosition Opaque key
HP_Location
ElementLocationTag for Internal HBAs: PCI Slot Number
Examples:
•
Slot=3 – for adapter in PCI Slot 3
•
Embedded Controller=7 – for Embedded adapter
where 7 is the internal identifier for the embedded
controller
ElementLocationTagDesc 23 (Adapter)—For Internal HBAs
LocationInformation[0] For internal HBAs: PCI Slot number
Examples:
•
3—PCI Slot 3
•
0—Embedded on Motherboard
LocationInfoDesc[0] 3 (PCI Slot)—For internal HBAs
(Embedded Device) – for internal HBA embedded on
Motherboard
HPSA_ArrayControllerLocation
