1. Locate the tape and lock at the top of the device (see Figure 10 on page 35) .
Figure 10 Shipping lock location
.
2. Remove the tape, then remove the lock.
3. Store the lock on the back panel of the device (see Figure 11).
Figure 11 Shipping lock storage location
.
Mounting the device in a rack
If you plan to set the Autoloader on a table or rack shelf, skip this step and continue with “Installing
the Tabletop Conversion Kit” on page 37.
WARNING!
The HP StorageWorks 1/8 G2 Tape Autoloader weighs 11.5 kg (25.4 lb) without media and 13.1
kg (28.9 lb) with media (8 cartridges). When moving the Autoloader, to reduce the risk of personal
injury or damage to the Autoloader: 1) observe local health and safety requirements and guidelines
for manual material handing, 2) always remove all tapes to reduce the overall weight of the Autoloader,
and 3) obtain adequate assistance to lift and stabilize the Autoloader during installation or removal.
The device easily installs into the HP Rack System/E, or the HP Rack 5000 or HP Rack 10000 series.
You need a #2 and a #3 Phillips screwdriver for this procedure.
Unpack the rack kit and verify that it includes the following:
HP StorageWorks 1/8 G2 Tape Autoloader User and service guide 35
