______HSD Technological equipment for Automation _____________________________________
5801H0017 Rev. 02 _________________________________________________________ 39/98
A label, shown in figure 7.2, is applied to the crate, stating its weight. The box corresponding to the
correct weight is checked (25 kg in the example shown).
GROSS WEIGHT
15 90
25
√
110
35 130
45 160
55 215
65 270
75 …
Figure 8.2 Label showing weight of crate
Do not lift the electro-spindle by the cooling fan cover. The cover could break and the
electro-spindle could fall, causing serious damage to the unit and injury to the operator.
The lifting diagrams reproduced here are merely examples of possible ways of lifting the
electro-spindle. HSD S.p.a. cannot foresee all possible lifting methods and
configurations for its electro-spindles.
THIS SYMBOL IS USED TO IDENTIFY POTENTIAL LIFTING POINTS.
