12.2.1 Changing the spindle shaft kit
To replace the spindle shaft kit, follow the instructions given in the “Spindle Shaft Kit Replacement
Manual” (code HSD 5802H0001) that comes with the kit and can be ordered from the Technical
Assistance Service.
i
ONLY FOR UNITS WITH BELT DRIVEN C AXIS:
On models with belt driven C axis, the spindle shaft kit must be replaced by HSD
technical assistance. Replacement by the customer is not permitted.
Figure 12.7 ES919 HSK F63 Short Nose spindle shaft kit
Figure 12.8 ES919 HSK F63 Long Nose spindle shaft kit
