HSD ES919 NC - Spare Parts List

______HSD Technological equipment for Automation _____________________________________
5801H0017 Rev. 02 _________________________________________________________ 96/98
§ 15 SPARE PARTS LIST
HSD CODE
DESCRIPTION
KS915INC
ES915 ISO 30 Short Nose spindle shaft kit
Version K+C: CRONIDUR or CHROMEX front bearings – Ceramic rear bearings
Version C+C: Ceramic front and rear bearings
Version C+A: Ceramic front bearings – steel rear bearings
Version A+A: Steel front and rear bearings
KS919INC
ES919 ISO 30 Short Nose spindle shaft kit
Version K+C: CRONIDUR or CHROMEX front bearings – Ceramic rear bearings
Version C+C: Ceramic front and rear bearings
Version C+A: Ceramic front bearings – steel rear bearings
Version A+A: Steel front and rear bearings
KS919INL
ES919 ISO 30 :Long Nose spindle shaft kit
Version K+C: CRONIDUR or CHROMEX front bearings – Ceramic rear bearings
Version C+C: Ceramic front and rear bearings
Version C+A: Ceramic front bearings – steel rear bearings
Version A+A: Steel front and rear bearings
KS919HNC
ES919 HSK F63 Short Nose spindle shaft kit
Version K+C: CRONIDUR or CHROMEX front bearings – Ceramic rear bearings
Version C+C: Ceramic front and rear bearings
Version C+A: Ceramic front bearings – steel rear bearings
Version A+A: Steel front and rear bearings
KS919HNL
ES919 HSK F63 Long Nose spindle shaft kit
Version K+C: CRONIDUR or CHROMEX front bearings – Ceramic rear bearings
Version C+C: Ceramic front and rear bearings
Version C+A: Ceramic front bearings – steel rear bearings
Version A+A: Steel front and rear bearings
6202H0011A
Cylinder assembly for : ES915 ISO30 , ES919 ISO30 , ES919 L ISO30
6202H0016A
Cylinder assembly for : ES919 HSK F63 , ES919 L HSK F63
5664H0001
Sensor S1
5664H0002
Sensor S2
5664H0006
Sensor S3
5664H0016
Sensor S4
5664H0024
Sensor SC (Belt driven “C” axis)
5664H0003
Temperature sensor for front bearings
6390H0001
Forced air cooling kit
5661H0001
Cooling fan kit (complete with basic cover and protective cover)
5618H0001
Push-button
6200H0045
“Signal + Power” cable connector
6200H0046
“ Power” cable connector
