1 2
HSK tool holder housing
(1) Conical surface (in black)
Figure 12.3
Conical surface of ISO 30 spindle
shaft (in black)
Figure 12.4
(2) Face (in grey)
Clean these parts carefully at the end of every working day with a clean and soft cloth.
BLOWING COMPRESSED AIR INTO THE SPINDLE NOSE WHEN
THERE IS NO TOOL HOLDER IN PLACE CAN CAUSE DAMAGE (Figure
12.5).
N
O
!
Figure 12.5
Follow the instructions in section 12.1.1 to
clean the tool holder housing in the spindle
nose.
