______HSD Technological equipment for Automation _____________________________________
5801H0017 Rev. 02 _________________________________________________________ 93/98
There is dirt or foreign
bodies between the tool
holder and the spindle
shaft housing
Remove any large foreign bodies
and clean the tool holder cone and
spindle housing as instructed in
section 12.1.2 .
The tool holder cone is not
of the right type
Choose a tool holder as instructed
in sections 11.4.1 (ISO 30), 11.4.2
(HSK) and 11.4.3 (all).
There is insufficient air
pressure to open the collet
• Check the air pressure settings
in accordance with section 9.4
• Check the compressed air
system for leaks and pressure
losses.
The electro-spindle is not
aligned with the tool holder
magazine
Consult the machine's own manual
or contact the machine
manufacturer.
Sensor S2 is disconnected
or faulty
• Check the sensor connectors.
• Check the sensor cables for
breaks.
• Calibrate the sensors as
instructed in section 12.2.4 .
• Replace any faulty sensors as
instructed in section 12.2.4 .
The tool holder is not locked
There is a control error
Consult the machine's own manual
or contact the machine
manufacturer.
There is insufficient air
pressure
• Check the air pressure settings
in accordance with section 9.4
• Check the compressed air
system for leaks and pressure
losses.
The tool holder is not ejected
There is no ejection
enabling signal
Consult the manuals or contact the
manufacturers of the machine,
numeric controller, and inverter.
There is no air pressure
inside the electro-spindle
There is insufficient air
pressure or the
compressed air system is
faulty
• Check the air pressure settings
in accordance with section 9.4
.
• Check the compressed air
system for leaks and pressure
losses.
• Contact the HSD Technical
Assistance Service.
One of the sensors does not
give the required output
A sensor is disconnected
or faulty
• Check the sensor connectors.
• Check the sensor cables for
breaks.
• Calibrate the sensors as
instructed in section 12.2.4 .
• Replace any faulty sensors as
instructed in section 12.2.4 .
