FusionModule2000 Smart Modular Data Center
Product Description
Copyright © Huawei Technologies Co., Ltd.
6.2.2.3 Electric Sliding Door
Figure 6-16 Electric Sliding Door
Electric Sliding Door can be opened only sideways, and therefore may involve risks during fire
extinguishing system acceptance.
6.2.3 M-shaped Cable Trough
Cabinet cable troughs are categorized into signal cable troughs and power cable troughs,
which are used to route signal cables and power cables respectively. This ensures that weak
current cables are separated from strong current cables.
A cable trough consists of several parts that are clamped together. A cable trough is assembled
using two brackets, one supporting plate, and one partition plate (used to separate
weak-current optical fibers from weak-current network cables and separate strong-current
route A from strong-current route B).
A cable trough is 170 mm high and 310 mm long.
