No.
Port Name
Description

Insert the USB flash drive, import and export the
configuration file, export run logs, and upgrade software.
6
RST
Restart switch for the MDU
7
SD
Reserved
8
DIP switch
Implements specific functions by using the DIP switch and
specific buttons; controls the CAN communication build-out
resistor in a parallel system
Functions
The monitor display unit (MDU) allows for general UPS operations, parameter setting,
viewing of running status and alarms, and so on.
Specifications
Dimensions (H x W x D): 175 mm x 264 mm x 40 mm
5.2.1.6 Technical Specification
Table 5-12 Physical specifications
Item
Specifications
Cable routing mode
Routed in and out from the top
Routed in and out from the bottom (tail frame configured)
Protection level
IP20
Dimensions (H x W x D)
2000 mm x 600 mm x 1100 mm
Communication
Dry contacts, RS485, and SNMP
Table 5-13 Environmental specifications
Item
Specifications
Operating temperature
0°C to 40°C
Storage temperature
–40°C to +70°C
Relative humidity
5%–95% RH (non-condensing)
Altitude
0–1000 m (When the altitude is greater than 1000 m and less
than 4000 m, the rated power should be derated. For details,
see the IEC62040-3.)
