FusionModule2000 Smart Modular Data Center
Product Description
5 Power Supply and Distribution System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
42
Table 5-14 Safety and EMC
Item
Specifications
Safety compliance
EN62040-1, 2013
IEC62040-1, 2013
Electromagnetic
compatibility (EMC)
EN/IEC62040-2
IEC61000-2-2
IEC61000-4-2
EN61000-4-6: EN/IEC62040-2 2nd Ed (IEC61000-4-6)
EN61000-4-3: EN/IEC62040-2 2nd Ed (IEC61000-4-3)
EN/IEC62040-2 2nd Ed (IEC61000-4-4)
EN/IEC62040-2 2nd Ed (IEC61000-4-5)
IEC61000-4-8
IEC61000-4-11
Table 5-15 Mains Input electrical specifications
Item
Specifications
Input system
Three-phase, four-wire, and PE
Rated input voltage
380 V AC/400 V AC/415 V AC (line voltage)
Input voltage range
80–280 V AC (phase voltage)
At 0–40°C: The UPS works at full load when the voltage is
176–280 V AC and is linear derated to 40% load when the
voltage is 176–80 V AC.
Input frequency range
40–70 Hz
Input power factor
> 0.99 (full load); > 0.98 (half load)
THDi
≤ 3% (linear load; maximum: 3%); ≤ 5% (non-linear load;
maximum: 5%)
Table 5-16 Bypass Input electrical specifications
Item
Specifications
Input system
Three-phase, four-wire, and PE
Rated input voltage
380 V AC/400 V AC/415 V AC (line voltage)
Input frequency range
50/60 Hz ±6 Hz (adjustable with the tolerance of 0.5–6 Hz, ±2
Hz by default)
