Huawei FusionModule2000 - Vcn520

FusionModule2000 Smart Modular Data Center
Product Description
8 Intelligent Module Management System
Issue 06 (2020-05-21)
Copyright © Huawei Technologies Co., Ltd.
188
Item
Specification
Weight in full configuration (including
disks)
≤ 5 kg
Maximum power consumption (including
hard disks)
< 60 W
Dimensions (H x W x D)
43.6 mm (1 U) x 442 mm x 310 mm
(excluding the panel)
43.6 mm (1 U) x 442 mm x 320 mm
(including the panel)
8.3.9.3 VCN520
Figure 8-42 Appearance
Table 8-54 Performance Specifications
Item
Specification
Device access and video storage
Supports a maximum of 32 video access
channels or 320 Mbit/s video access
bandwidth.
Video forwarding
Supports a maximum of 128 video
forwarding channels or 320 Mbit/s video
forwarding bandwidth.
Video playback and download
Supports a maximum of 32 video playback
and download channels or 320 Mbit/s video
playback and download bandwidth.
Ingress and egress bandwidth
The ingress bandwidth does not exceed 320
Mbit/s.
The egress bandwidth does not exceed 320
Mbit/s.
NOTE

If cameras are connected through the GB/T
28181 or DHSDK protocol, both the ingress
bandwidth and egress bandwidth do not
exceed 256 Mbit/s.

In the cluster or external domain connection
scenario, the ingress bandwidth and egress
bandwidth of the master server do not exceed
256 Mbit/s separately.
